热丝电压 Uh…………………………............................. 6.3 V Ih…………………………...............................1.85 A 极间电容 输入电容…………………...........................20.5 PF 输出电容…………………............................10 PF 跨路电容…………………............................1.75 PF 最大额定值 Ua(四级管连接) ……………………............850 V Ua(三极管连接) …………………….............650 V Ug2（五极管连接）………………..........650 V Ug2（三极管连接）………………..........600 V Ug1…………………………...........................-200 V Pa…………………………............................. 70 W Pg2…………………………............................9 W Ik(五极管链接) ……………………............250 mA Ik(三极管链接) ……………………............250 mA Uhk…………………………...........................±300 V Rg1 固定偏压时......................................51 kΩ 自偏压时.........................................240 kΩ 玻壳温度.............................................250 ℃ 典型工作状态 Ua………………….......................................400 V Ug2………………........................................225 V Ia………………….........................................165 mA Ig2(max) ………………….............................15 mA Ug1………………….....................................-14 V Gm………………….....................................12.6 mA/V RL …………………........................................3 KΩ Pout …………………………...........................20 W Dtot…………………………...........................≤14.0 % |
